Frame SLR OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel
Fork Fox Factory 34 SL, Float EVOL air spring, GRIP SL 2- position damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt X axle, 110 mm travel
Shock Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper
Max compatible fork travel Max: 120 mm (533 mm axle-to-crown), min: 100 mm (505 mm axle-to-crown)
Wheels
Wheel front Bontrager Kovee RSL, OCLV Mountain Carbon, Tubeless Ready, CentreLock, Boost110, 15 mm thru axle, 29"
Wheel rear Bontrager Kovee RSL, OCLV Mountain Carbon, Tubeless Ready, CentreLock, Boost148, 12 mm thru axle, 29"
Skewer rear Bontrager Switch thru axle, removable lever
Tyre Maxxis Aspen, Tubeless Ready, EXO casing, folding bead, 29x2.4"
Tyre part Bontrager TLR sealant, 180 ml/6 oz
Rim strip Bontrager TLR
Max tyre size Frame: 29x2.40", Fork: See manufacturer
Drivetrain
Shifter Shimano XTR Di2 M9250, 12-speed
Rear derailleur Shimano XT M9250, long cage
*Crank Size: S, M, ML
E*thirteen Helix Race Carbon, 34T, 55 mm chain-line, 170 mm length
Size: L, XL
E*thirteen Helix Race Carbon, 34T, 55 mm chain-line, 175 mm length
Bottom bracket E*thirteen BB20-92
Cassette Shimano XT M9200, 10-51, 12-speed
Chain Shimano Dura-Ace/XTR M9100, 12-speed
Max. chainring size 1x: 38T, min 30T
Components
Saddle Aeolus RSL, carbon rails, 145 mm width
*Seatpost Size: S, M
Fox Transfer SL, 100 mm travel, internal routing, 31.6 mm
Size: ML, L
Fox Transfer SL, 125 mm travel, internal routing, 31.6 mm
Size: XL
Fox Transfer SL, 150 mm travel, internal routing, 31.6 mm
*Handlebar/stem (integrated) Size: S, M, ML
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 70 mm length
Size: L
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 80 mm length
Size: XL
Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 0 mm handlebar rise, 750 mm width, -13-degree stem rise, 90 mm length
Head set FSA IS-2, 1-1/8" top, 1.5" bottom
Brake Shimano XTR M9200 hydraulic disc
*Brake rotor Size: S, M, ML, L, XL
Shimano MT900, 180 mm
Size: S, M, ML, L, XL
Shimano MT900, CentreLock, 160mm
