- Shock absorbers
- Rigid
- Handlebars
- Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80mm reach, 124mm drop, 41cm control width, 44cm drop width, 110mm stem length
- Tyres
- Bontrager Aeolus RSL RD, Tubeless Ready, cotton construction, aramid bead, 170 tpi, 700x28mm
- Brake type
- Hydraulic disc
- Frame (Full spec)
- 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
- Cranks
- Shimano Ultegra R8100, 50/34
- Frame material
- Carbon
- Monoblock
- Praxis, T47 threaded, internal bearing
- Number of speeds
- 2x12
- Seat post
- Madone aero carbon seatpost, 0mm offset, short length
- Cassette
- Shimano Ultegra R8101, 11-34, 12 speed
- Fork
- Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
- Chain
- Shimano XT M8100, 12 speed
- Seat (Saddle)
- Bontrager Aeolus Pro, carbon rails, 145 mm width
- Wheel Size
- 700c
- Brakes
- Shimano Ultegra
- Front derailleur
- Shimano Ultegra R8150 Di2, braze-on, down swing
- Rear derailleur
- Shimano Ultegra R8150 Di2, 34T max cog
- Model line
- TREK Madone
- Model year
- 2026
- Ride+ Battery
- Shimano BT-DN300
- Brake Lever Left
- Shimano Ultegra
- Brake Lever Right
- Shimano Ultegra
- Shifter Left
- Shimano Ultegra R8170 Di2, 2 speed
- Shifter Right
- Shimano Ultegra R8170 Di2, 12 speed
- Front Wheel
- Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12mm thru axle
- Rear Wheel
- Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12mm thru axle
